Compare Headsets

EMOTIV's range of electroencephalogram (EEG) Brainwear®.
  • Technical Specification
  • Detections
  • Configurable Options
  • Prerequisites
DESCRIPTION

Sensor Count

Sensor Locations

Resolution

LSB Resolution

Dynamic Range

Sensor Technology

Motion Sensor
Connectivity
Connectivity
Connectivity
Connectivity

Battery Life

References
Sample Rate
Contact Quality
Frequency Response
INSIGHT 2.0

Sensor Count: 5 (+2 references)

Sensor Locations: AF3, AF4, T7, T8, Pz
Resolution: 16 bits per channel
LSB Resolution: 0.1275µV (16 bits mode)

Dynamic Range: ±4.17 mV

Sensor Technology: Long life semi-dry polymer
Motion Sensor: 9 axis sensor (4 quaternions, 3x accelerometer, 3x magnetometer)
Connectivity: -
Connectivity: Bluetooth® Low Energy
Connectivity: BT5 Ready
Connectivity: Extender Support – future feature.
Battery Life: Up to 20 hours
References: CMS/DRL references on left mastoid process
Sample Rate: 2048 internal downsampled to 128 SPS
Contact Quality: Realtime CQ monitor (patented)
Frequency Response: 0.5 – 43 Hz
EPOC X

Sensor Count: 14 (+2 references)

Sensor Locations: AF3, AF4, F3, F4, FC5, FC6, F7, F8, T7, T8, P7, P8, O1, O2
ReSolution: 14 bits or 16 bits per channel
LSB Resolution: 0.51µV (14 bits mode), 0.1275µV (16 bits mode) (user configured)

Dynamic Range: ±4.17 mV

Sensor Technology: Saline soaked felt pads
Motion Sensor: 9 axis sensor (4 quaternions, 3x accelerometer, 3x magnetometer)
Connectivity: Proprietary USB receiver (included): 2.4GHz band.
Connectivity: Bluetooth® Low Energy
Connectivity: BT5 Ready
Connectivity: USB 2.0 (with Extender) Support for EMOTIV Extender will be available with upcoming software and firmware updates.
Battery Life: Up to 9 hours
References: CMS/DRL references at P3/P4; left/right mastoid process alternative
Sample Rate: 2048 internal downsampled to 128 SPS or 256 SPS (user configured)SPS
Contact Quality: Realtime CQ monitor (patented)
Frequency Response: 0.16 – 43 Hz
EPOC FLEX

Sensor Count: Up to 32 (+ 2 references)

Sensor Locations: Configurable in any 10-20 location
ReSolution: 14 bits per channel slew rate limit 65µV/sample
LSB Resolution: 0.51μV

Dynamic Range: ±4.17 mV

Sensor Technology: Saline OR Ag/AgCl + Gel
Motion Sensor: 9 axis sensor (4 quaternions, 3x accelerometer, 3x magnetometer)
Connectivity: Proprietary USB receiver (included): 2.4GHz band.
Connectivity: Bluetooth® Low Energy
Connectivity:
Connectivity: USB 2.0 (with Extender)
Battery Life: Up to 9 hours
References: CMS/DRL configurable in any 10-20 location or on ears (contains compatible ear clips for sensors – Gel model only )
Sample Rate: 1024 internal downsampled to 128 SPS
Contact Quality: Realtime CQ monitor (patented)
Frequency Response: 0.16 – 43 Hz
MN8

Sensor Count: 2 (+4 references)

Sensor Locations: Left and Right Ear Canal
ReSolution: 14 bits per channel
LSB Resolution: 0.51 µV

Dynamic Range: ±4.17 mV

Sensor Technology: Dry non-toxic non-allergenic conductive elastomer earbud
Motion Sensor: 6 axis sensor, 4 quaternions
Connectivity:
Connectivity: Bluetooth® Low Energy
Connectivity:
Connectivity: USB 2.0 (firmware updates and headset charging only)
Battery Life: Up to 6 hours
References: Averaging circuit using Split CMS, split DRL sensors on rear of ear flap (pinna)
Sample Rate: 8kHz, filtered and down-sampled to 128Hz
Contact Quality: Realtime CQ monitor (patented)
Frequency Response: 0.16 – 45Hz
DESCRIPTION

Facial Expressions

Emotional States

Mental Commands

INSIGHT

Facial Expressions:

  Blink Wink Left/Right Furrow (frown) Raise Brow (surprise) Smile Clench Teeth (grimace) - - -
Emotional States: Excitement Long term excitement Stress Engagement Relaxation Interest/Affinity Focus
Mental Commands: Mental Commands: Neutral + up to 4 pretrained items from a list of 13 labels: Push Pull Lift Drop Left Right Rotate clockwise Rotate anti-clockwise Rotate forwards Rotate backwards Rotate left Rotate right Disappear
EPOC X

Facial Expressions:

Blink Wink Left/Right Look Left/Right Furrow (frown) Raise Brow (surprise) Smile Clench Teeth (grimace) Laugh Smirk Left/Right
Emotional States: Excitement Long term excitement Stress Engagement Relaxation Interest/Affinity Focus
Mental Commands: Mental Commands: Neutral + up to 4 pretrained items from a list of 13 labels: Push Pull Lift Drop Left Right Rotate clockwise Rotate anti-clockwise Rotate forwards Rotate backwards Rotate left Rotate right Disappear
EPOC FLEX

Facial Expressions:

Blink Wink Left/Right Look Left/Right Furrow (frown) Raise Brow (surprise) Smile Clench Teeth (grimace) Laugh Smirk Left/Right
Emotional States: Excitement Long term excitement Stress Engagement Relaxation Interest/Affinity Focus
Mental Commands: Mental Commands: Neutral + up to 4 pretrained items from a list of 13 labels: Push Pull Lift Drop Left Right Rotate clockwise Rotate anti-clockwise Rotate forwards Rotate backwards Rotate left Rotate right Disappear
MN8

Facial Expressions:

TBA - - - - - - - -
Emotional States:   Cognitive Stress More to come - - - - -
Mental Commands: Mental Commands: TBD - - - - - - - - - - - - -
DESCRIPTION

User Configurable Options

INSIGHT

User Configurable Options:

  None
EPOC X

User Configurable Options:

  14 bits/16 bits voltage resolution Enable/disable individual motion sensors (accelerometer, gyro, magnetometer)
EPOC FLEX

User Configurable Options:

  14 bits/16 bits voltage resolution Enable/disable individual motion sensors (accelerometer, gyro, magnetometer)
MN8

User Configurable Options:

  None
DESCRIPTION

Supported Platforms

*Note: Also subject to software and SDK compatibility
INSIGHT

User Configurable Options:

  Windows 10 (64-bit) v1607+ Mac OSX 10.13 and higher iOS 12 or above (Beta release) Android 7.0 Nougat (API level 24) or above (Beta release)
EPOC X

User Configurable Options:

  Windows 10 (64-bit) v1607+ Mac OSX 10.13 and higher iOS 12 or above (Beta release) Android 7.0 Nougat (API level 24) or above (Beta release)
EPOC FLEX

User Configurable Options:

  Windows 10 (64-bit) v1607+ Mac OSX 10.13 and higher
MN8

User Configurable Options:

  Windows 10 (64-bit) v1607+ Mac OSX 10.13 and higher Requires a USB-Bluetooth™ music streaming dongle, uses internal Bluetooth™ Low Energy receiver for EEG data
