14-CHANNEL WIRELESS EEG HEADSET
The World’s
#1 Wireless EEG Headset
Capture Research-Grade EEG Data Anywhere with EPOC X. EMOTIV’s Pioneering Wireless EEG Headset.
Your Powerful Brainwave Monitoring Partner
Seamlessly capture raw EEG data, decode brain activity with EMOTIV’s Performance Metrics, and more with Pro.
Designed for Scalable and Contextual Human Brain Research
10-20 Sensor Configuration
Captures high-quality, research-grade EEG data.
Democratizing Brain Research
Enables limitless research and diverse sample sets.
Connects seamlessly with EMOTIV’s applications
Efficient, Real-time EEG data transmission.
Truly understand the human experience
Conduct research in the real world.
Removes interferences and artifacts
Captures reproducible EEG data.
Enhanced Comfort with a Rotating Headband
EPOC X’s rotating headband can be positioned at the top or rear of the head, enabling more comfortable data collection — including sleep studies and users who need headrest support.
Easy Sensor Rehydration
Rehydrate each sensor easily while EPOC X is worn through its rear opening — reducing interruptions during experiments and enabling experiments to run for longer durations.
Full Specifications
EEG sensors
14 channels: AF3, F7, F3, FC5, T7, P7, O1, O2, P8, T8, FC6, F4, F8, AF4
2 references: CMS/DRL references at P3/P4; left/right mastoid process alternative
Sensor material: Saline soaked felt pads
Motion sensors
IMU part: ICM-20948
Quaternions: normalized, 4D
Resolution: 16 bits
Connectivity
Wireless: Bluetooth® Low Energy (improved connectivity with new antenna) Bluetooth® 5.0 Ready – We currently use Bluetooth® SMART (also known as Bluetooth 4.0 Low Energy Protocol) support for Bluetooth® 5.0 will be available with upcoming software and firmware updates.
Proprietary USB receiver: 2.4GHz band
USB: to change headset settings & Extender
Available detections
Mental Commands: neutral + up to 4 pre-trained items per training profile
Performance Metrics: Excitement, Engagement, Relaxation, Interest, Stress, Focus
Facial Expressions: Blink, Wink L/R, Surprise, Frown, Smile, Clench, Laugh, Smirk L/R
EEG signals
Sampling method: Sequential sampling, single ADC
Sampling rate: 2048 internal downsampled to 128 SPS or 256 SPS (user configured)
Resolution: LSB = 0.51µV (14 bits mode), 0.1275µV (16 bits mode)
Bandwidth: 0.16 – 43Hz, digital notch filters at 50Hz and 60Hz
Filtering: Built in digital 5th order Sinc filter
Dynamic range (input referred): 8400 μV(pp)
Coupling mode: AC coupled
Power
Battery: Internal Lithium Polymer battery 595mAh
Battery life: up to 12 hours using USB receiver, up to 6 hours using Bluetooth Low Energy
Weight
170g
Dimensions
9 x 15 x 15 cm
Develop with EMOTIV
Interested in developing an app with EPOC X?
Create personalized experiences and activations using real-time brain data with EMOTIV’s Software Development Kit.
Explore EMOTIV’s EEG Devices
14 sensors
Sensor Technology:
Saline soaked felt
Refill Merchanism
5.0 Ready
Higher data quality
Sensor Location:
Fixed
Headband:
Rotating
Set-up time:
15-30 mins
32 sensors
Sensor Technology: Saline
Refill Merchanism
Version 4.0
Highest data quality
Sensor Location:
Configurable
–
Set-up time:
15-30 mins
32 sensors
Sensor Technology:
Gel
–
Version 4.0
Highest data quality
Sensor Location:
Configurable
–
Set-up time:
15-30 mins
5 sensors
Sensor Technology:
Semi-dry polymer
–
5.0 Ready
Good data quality
Sensor Location:
Fixed
Headband:
Fixed position
Set-up time:
1-2 mins
2 sensors
Sensor Technology:
Dry non-toxic non-allergenic conductive elastomer
–
5.0 Ready
–
Sensor Location:
Fixed
–
Set-up time:
1 min
